⚙️ Specifications:
- Model: 150W DC-DC Boost Converter Step-Up Power Supply Module
- Input Voltage: 10V – 32V DC
- Output Voltage: 12V – 35V DC (Adjustable via Potentiometer)
- Max Input Current: 10A (with cooling)
- Max Output Power: 150W
- Conversion Efficiency: Up to 95%
- Switching Frequency: 150kHz
- Output Ripple: < 100mV
- Load Regulation: ±0.5%
- Short Circuit Protection: No (use fuse if required)
- Cooling Method: Passive / Active (optional fan for high current)
- Module Size: Approx. 6.5 × 4.7 × 2.1 cm
- Weight: About 60g
🌟 Key Features:
⚡ High Efficiency (Up to 95%) – Ensures low heat and stable performance. 🔧 Adjustable Output Voltage – Fine-tune voltage with onboard potentiometer. 🔥 High Power Output (150W) – Supports up to 10A current with heat sink. 💡 Wide Input Range (10–32V) – Compatible with batteries, solar panels, or adapters. 🧠 Stable Step-Up Regulation – Converts lower voltage to higher without fluctuations. 🔋 Durable Design – Heavy-duty components with integrated heat sink for long life. 🔌 DIY Friendly – Ideal for makers, engineers, and electronics enthusiasts.
💡 Applications:
- DIY Adjustable Power Supply
- Solar Power Boost System
- Battery-Powered Devices & Chargers
- LED Lighting & Strip Power Supply
- Electric Vehicle or E-Bike Projects
- Arduino, IoT, and Robotics Power Modules
- Car, Boat, or Camping Power Converter
📦 Package Includes: 1 × 150W DC-DC Boost Converter Step-Up Power Supply Module
